Fleetguard AF25708M High-Efficiency Air Filter

Description

Fleetguard AF25708M Magnum RS™ Radial Seal Air Filtration

The Fleetguard AF25708M Air Filter is a Magnum RS™ Radial Seal Primary Air Filtration. The Fleetguard Magnum RS™ radial seal primary and safety air filter elements provide total coverage for all your on and off-highway trucks and equipment. Designed to meet the rugged demands of equipment that operates in the harshest environments, the Magnum RS radial seal primary and safety air elements provide REAL™ Value. Magnum RS offers unique features that provide significant benefits for longer service life and optimum performance levels when the job demands it.

The Fleetguard® Cummins Filtration OptiAir™ AF25708M primary air element is designed for installation into these Air Handlers:

• AH8736
• AH19257
• AH19266
• AH19273
• AH19274

Advantages of the Cummins Filtration Fleetguard AF25708-M Primary Air Filter Element:

• Better airflow for maximum engine life
• Greater capacity and durability for longer service intervals
• Road-tested for over 20 years
• OEM approved

Cummins Filtration – Fleetguard AF25708M Dimensions:

• Overall OD: 279.4 mm or 11.0″
• Overall Height: 520.7 mm or 20.5″
• Inside Diameter: 205.74 mm or 8.10″

Fleetguard AF25708-M Primary Air Filter Element Applications:

• AH19257 Air Handler
• AH19266 Air Handler
• AH19273 Air Handler
• AH19274 Air Handler

Cummins Filtration – Fleetguard AF25708-M cross-references:

• NELSON 870904A
• NELSON 870904N
• BALDWIN RS4993
• DONALDSON P613333
• NAPA 9078
• WIX 49708

The Fleetguard AF25708M filter is used as the Primary Air Filter Element on the following:

• Cummins QSZ13 366-500kVA 50 Hz / 323-440 kW 60 Hz 13 Liter 6 cylinder diesel engines.

This Fleetguard AF25708M Primary Air Filter is used with the AF25545 Secondary Magnum RS Air Filter.

• Engine : Cummins QSZ13-G5 | Cummins QSZ13-G7
• Flow Rate :
• Item Number: AF25708M
• Make: Cummins
• Manufacturer Part No: AF25708M
• Product Application: Primary air filter elements for Cummins
• Height: 12
• Width: 24
• Brand: Fleetguard – Atmus Filtration Technologies
• FAQ: What is the difference between a Magnum and non-Magnum air filter element? The Fleetguard® Magnum RS™ air filter boasts a radial seal primary element that can withstand tough conditions, providing exceptional durability and improved performance. An excellent choice for demanding equipment, it outperforms non-Magnum air filters, which lack the exclusive Magnum RS features.
• Part Number: AF25708M
• Manufacturer: Fleetguard
• Product Note: This is the Primary Air Filter element used on the Cummins Power Generation C450 D5EB Generator Engine
